Specialty Lenses
-27D BLENDED DOUBLE MYO.
Franklin with Blended Rd 28
Franklin with Blended Rd 28
Allow 4 to 5 weeks for completion
Franklin with Blended Rd 28
Franklin with Blended Rd 28
Franklin with Blended Rd 28
Allow 4 to 6 weeks for completion
14D Cylinder HD on -4.d
Franklin with Blended Rd 28
14D Cylinder HD on -4.d
Allow 4 to 6 weeks for completion
mYo-Lenticular SUPER MODULAR
mYo-Lenticular SUPER MODULAR
mYo-Lenticular SUPER MODULAR
From -1.00 to -6.00 back side correction on super modular HD Myo-Lenticular.
Executive back blended rd 28
mYo-Lenticular SUPER MODULAR
mYo-Lenticular SUPER MODULAR
Available segments range from 8 -28 mm. Addition from 1.00 - 6.00D
All Myodisc & Slab-off
mYo-Lenticular SUPER MODULAR
All Myodisc & Slab-off
Allow 4 to 6 weeks for completion
Franklin with HD Rd28. Super Module Design
pic. specs: -4.00 Distance With 6 base PRISm-in applied on add power of +4.00, Blended Rd28 Franklin Design
Prism up to 6D on reading portion, combined with blended Round Seg up to +6.00 add power.
Frame restrictions may apply
4 to 6 weeks turnaround time
Blended sINGLE & Double Myo-Disc. Super MODULE Design
BACK HD SUPER MODULAR with Blended polish edge
Myo-Disc up to -27D Standard and Double Myo with Polish Facet
Front blended Facet to Knife edge
Pic. Specs.
-24D. power with 48 mm opening field. 1.67 material
*Max power -27D on extra thick blank 1.74
4 to 6 weeks turn-around time
Double Sided Myo-disc Standard
Max to-24D on extra-thick blank -1.74 2Bc material
3 to 5 weeks turn-around time
Axis split with OVER-POWER cylinder up to 16d
BACK HD SUPER MODULAR Hi Cylinder Power
Cyl. up to -18D keratoconus patients who may not be suitable candidates for contact lenses
Correction for patients off contact lenses with Polish Facet
Front blended Facet Modular design to Knife edge
Pic Specs: -3.00 +14.00 x 110
Maximum CYL. power up to 16D on cr39 -1.6 - 1.67 and 1.74 material
Not available in poly, Trivex and Transitions
4 to 6 weeks turn-around time
VOCAtiONAL STD. Design + combineD with progressive hd
BACK HD Rd 28 mm with semi blended Executive
Rd. Seg. size available upon request from 8mm to 40 mm. Ultex design (larger than 28 will be blended as Semi Round Design)
Executive line manufactured by single point blade 1mm. Straight line blended on back side throughout the lens
HD Progressive vocational with blended Rd 30
4 to 6 weeks turn-around time
HD progressive vocational with Ft 28
HD progressive short corridor will manufacture on semi blended Flat-Top or Tri-focal 28 mm. or 35 mm. Also available as traditional vocational Double-D with 60/100 or 100/100
4 to 6 weeks turn-around time
